RGB LED Billboards P4 Outdoor High Brightness High Resolution HD IP65 for Advertising
Details:
This product has two forms: fixed (iron cabinet) and rental (cast aluminum cabinet).
If you don't move often, you can choose the fixed type; but if you need to change the place of use frequently, the rental type is better. Therefore, the weight difference between the two products is large.
Payment method:
30% prepayment, 70% before shipment.
Delivery time: 10-12 working days after receiving the deposit.
Warranty: Free repair warranty period is 2 years.
Specifications of product:
Outdoor P4 LED screen Display | |||||
Resolution/mm | 4 | ||||
Pixel configuration | 1R1G1B | ||||
Pixel density/pixels/m² | 62500/square meter | ||||
Module resolution | 64*32mm | ||||
Module size/mm | 256*128mm | ||||
View distance | ≥4m | ||||
Single point brightness adjust | Can be added | ||||
Single point color adjust | Can be added | ||||
White balance brightness | >1000cd/square meter | ||||
Color temperature | 6500K-9500K | ||||
Horizontal view angle | 120(degrees) | ||||
Vertical view angle | 60(degrees) | ||||
Signal Process bit | 10 or 16bit | ||||
Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
Driving mode | Constant driving current | ||||
Scanning mode | 1/8 | ||||
Fresh rate | 60Hz | ||||
Refresh frequency | >1000Hz | ||||
Control mode | Computer synchronous | ||||
Out of control point | <1/10000 | ||||
Aging hours | ≥72hours | ||||
Mean Time Between Failure | >5000hours | ||||
Life time | 100000hours | ||||
Life-all-white(brightness halving) | 50000hours | ||||
Environment temperature range | Operating temperature range: -20-45℃ | ||||
Self-check technology | LED spot self-check, communications check, power check, | ||||
temperature monitor(need customization) | |||||
Remote monitoring | Remote supervision and control, record potential fault, | ||||
send out warning signs to the operators.(need customization) | |||||
Software environment | WindowsNT,Windows1999,WindowsXP | ||||
Luminous point width between centres | Deviation<3% | ||||
Brightness uniformity | <10% | ||||
Color uniformity(chromaticity coordinate) | ±0.003 | ||||
Power supply request | AC85-264V(50Hz-60Hz) | ||||
Contrast | (1000:1) | ||||
System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
Humidity(working) | working:10-95% | ||||
Humidity(storing) | storing:10-95% |
Advantage
1. We have the advantage of a full range of LED display production
2: Goods supply from indoor and outdoor P10, P8, P6, P4,P3,P3.91,
P4.81, P2, P2.5, P1.976 have sufficient inventory, at the same time
has high quality, let you buy at ease, use at ease
3. We have round-the-clock online customers to help customers and
give customers product performance introduction, as
wellasproduct advantage analysis; According to the actual situation
and the use of the situation, for the customer
evaluation,choosethe most reasonable scheme
4: At the same time, we can provide customers with professional
training on the operation and maintenance of the led display
system Display troubleshooting
![]() |
