Factory Price Small Pitch Rental P2.604 Stage Indoor HD LED Display Video Wall

Shenzhen ShiXin Display Technology Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Factory Price Small Pitch Rental P2.604 Stage Indoor HD LED Display Video Wall from wholesalers

    Buy cheap Factory Price Small Pitch Rental P2.604 Stage Indoor HD LED Display Video Wall from wholesalers
    • Buy cheap Factory Price Small Pitch Rental P2.604 Stage Indoor HD LED Display Video Wall from wholesalers
    • Buy cheap Factory Price Small Pitch Rental P2.604 Stage Indoor HD LED Display Video Wall from wholesalers
    • Buy cheap Factory Price Small Pitch Rental P2.604 Stage Indoor HD LED Display Video Wall from wholesalers
    • Buy cheap Factory Price Small Pitch Rental P2.604 Stage Indoor HD LED Display Video Wall from wholesalers

    Factory Price Small Pitch Rental P2.604 Stage Indoor HD LED Display Video Wall

    Ask Lasest Price
    Brand Name : SCXK
    Model Number : SCXK-P2.604
    Certification : CE ,RoHS, FCC.CCC,SAA ,TUV ,UL
    Price : 1400-1600USD
    Payment Terms : T/T, Western Union
    Supply Ability : 5000sqs/month
    Delivery Time : 7-10 working days after payment
    • Product Details
    • Company Profile

    Factory Price Small Pitch Rental P2.604 Stage Indoor HD LED Display Video Wall


    Cheap Price Small Pixel Pitch Rental P2.604 Stage Indoor Led Display Video Walls


    Our company:
    SCXK has been specialized in LED field since 2005. We are a leading manufacturer and provider of technical solution of full color indoor an outdoor ledisplay,rental LED display, led modules where in Shenzhen ctiy,Guangdong province,China.

    Our advantages:
    1.Continues Quality
    With more than 10 years experience in led display producing,equipments are updated regularly.What’s
    more,unique standardized and module production ensure our products continuous quality.

    2.Competitive Price
    With large scale production capacity and professional production technology,our company have built
    effective modular production.We always stick to promote the technical innovation and reduce cost to
    benefit customers.

    3.Fast Delivery
    Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
    inventory will be used to maintain your uninterrupted supply of the products.

    4.Perfect Service
    Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
    you.

    After-sales:We will track the products usage and then constantly perfect our products.


    Specifications :

    SMD P2.604
    Lamp size2121
    Resolution/mm2.604
    Pixel configurationRGB 3 in 1
    Pixel density/pixels/m²147474/square meter
    Module resolution96x96
    Module size/mm250x250
    View distance≥2m
    Single point brightness adjustCan be added
    Single point color adjustCan be added
    White balance brightness>8000cd/square meter
    Color temperature6500K-9500K
    Horizontal view angle120(degrees)
    Vertical view angle60(degrees)
    Signal Process bit10 or 14 bit
    Grey process1024x1024x1024 16834x16834x16834 65536x65536x65536
    Control distancesInternet cable:100m, multimembrane:500m, monofilm:5km
    Driving modeConstant driving current
    Scanning mode1/32
    Frame rate60Hz
    Refresh frequency>4200Hz
    Control modeComputer synchronous
    Brightness adjusted rangeManual, automatic operation, stepless continuous adjusted
    255 steps. No grey loss
    Out of control point<1/10000
    Working hours≥72hours
    Mean Time Between Failure>5000hours
    Life time100000hours
    Life-all-white(brightness halving)50000hours
    Environment temperature rangeOperating temperature range: -20-45℃ Storing temperature range: -30-65℃
    Maximum power:/square meter<1000W
    Average power:/square meter<280W
    Self-check technologyLED spot self-check, communications check, power check,
    temperature monitor(need customization)
    Remote monitoringRemote supervision and control, record potential fault,
    send out warning signs to the operators.(need customization)
    Software environmentWindowsNT,Windows1999,WindowsXP
    Luminous point width between centresDeviation<3%
    Brightness uniformity<10%
    Color uniformity(chromaticity coordinate)±0.003
    Power supply requestAC85-264V(50Hz-60Hz)
    Contrast(1000:1)
    System protectionMoistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
    Humidity(working)working:10-95%
    Humidity(storing)storing:10-95%

    Factory Price Small Pitch Rental P2.604 Stage Indoor HD LED Display Video WallFactory Price Small Pitch Rental P2.604 Stage Indoor HD LED Display Video WallFactory Price Small Pitch Rental P2.604 Stage Indoor HD LED Display Video Wall

    ♦ Production process

    1) Incoming Inspection→2)DIP→3)Plug-in
    →4) Wave Soldering→5)After Welding→6)Testing
    →7) Semi Finished Aging→8)Module Assembly
    →9) Gluing→10)Finished Aging→11)Detection Finishing Warehousing


    The shipping details:



    Our certifications:
