P8 Indoor rental cabinet RGB LED Display technology led / high
resolution led display / custom led display
Why choose us?
With more than 8 Years of experience in producing LED modules, we
have passed CE, RoHS and ISO9001 certifications, and we always put
quality on the top of our list, because we firmly believe "Quality
is the lifeline for a corporation".
Usage for indoor and Outdoor
1.Sports
2.Advertisement
3.Enterainment
4.Stage& Events& Rental
5.TV Studio
Specifications :
| outdoor SMD P8 |
| Resolution/mm | 8 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 15625/m² |
| Module resolution | 32x16 |
| Module size/mm | 256x128 |
| View distance | 14-300m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >7500cd/㎡ |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | 1/4SCANNING |
| Frame rate | 60Hz |
| Refresh frequency | >3000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Self-check technology | LED spot self-check, communications check, power check, |
| temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature
protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
Other products:
Indoor fixed LED display: P2.5, P3, P4, P5, P6, P8, P10
Indoor rental LED display: P3, P3.9, P4, P4.8, P5, P6
Outdoor fixed LED display: P5, P6, P8, P10
Outdoor rental LED display: P3.9, P4.8, P5, P6, P6.25, P8, P10
Small pitch LED display: P1.6, P1.9
Front service maintenance LED display: P6.67, P8, P10
Stadium perimeter LED display: P8, P10
LED poster player: P2.5, P3, P4, P5, P6, P8, P10
