    Outdoor Rental/Die-Cast Aluminum P5 LED Display Module 1/16 Scanning 640*640mm Cabinet Waterproof Large Event

    Ask Lasest Price
    Brand Name : SCXK
    Model Number : SCXK-P5
    Certification : CE,RoHS,FCC,CCC,SAA,TUV,UL
    Price : Negotiations
    Payment Terms : T/T, Western Union, Western Union
    Supply Ability : 5000sqs/month
    Delivery Time : 7 working days after payment
    • Product Details
    • Company Profile

    Outdoor Rental/Die-Cast Aluminum P5 LED Display Module 1/16 Scanning 640*640mm Cabinet Waterproof Large Event

    P5 Outdoor LED Display Module 1/16 Scan 640*640mm Cabinet IP65 64*32 Resolution


    About us:


    Shenzhen ShiChuangXin Ke Electronic Co.,Ltd. established in 2005, is a high-tech enterprise which mainly concentrate on the R&D, Production, Sales and Service of the LED screen and solutions. With the advance technology, strong ability of R&D and resource integration, we will provide high-efficiency & top quality products to all over the world. Nowadays, our products have been exported to Europe,USA,Japan,German,South-East Asia,Middle-East and Africa, etc.


    Parameter Description
      Specifictions
    LED LampsType3mm smd2727
    LED StandardReal Pixel(1R1G1B)
    Red Wavelength625-630nm
    Green Wavelength520-530nm
    Blue Wavelength465-475nm
    LED ModulePixel Pitch5mm
    Module Size320mmx160mm
    Module Resolution64*32dots
    LED CabinetCabinet Size640mmX640mm
    Cabinet Resolution128pixels * 128pixels
    Cabinets MaterialAluminum Cabinet
    LED DisplayPixel Density40000pixels/sq.m
    Drive ICET6024
    Power SupplySeries connection
    Brightness≥6000cd/sqm
    Display Color16.7million
    Viewing Angle120°(Horizontal),60°(Vertical)
    Best Viewing Distance5m~150m
    Max Power Consumption800 w/sq.m
    Average Power Consumption  300 w/sq.m
    Weight28Kgs/sq.m
    Refresh Rate480hz
    Input VoltageAC220V/50H or AC110V/60H
    Output VoltageDC5V,40A
    Grey Scale Levels10bits/1024levels
    Display ColorsR(1024) x G(1024) x B(1024)
    MTBF5,000 hours
    Life-span100,000 hours
    Protection LevelIP65
    Failure percentage of leds  less than 0.0003
    Working Temperature-20℃~60℃
    Drive Mode1/8 scan
    Working Humidity10%~99%
    Control SystemControl methodSynchronization & Asynchronization
    Control SystemLINSN Control System (sender,receiver,HUB with 75 interface,software)
    SoftwareLED Studio (LINSN)
    Input SignalMPG/MPEG/MPV/MPA/AVI/VCD/SWF/RM/RA/RM/ASF/BMP/GIF/PCX/TXT/DOC.etc
    PC Operating systemMicrosoft Windows 7, 98, 2000, XP and Vista

    FAQ

    Q1: What's the warranty of your LED Display Screen ?

    A1: We have a 3-year warranty for our led display screen, and 100,000 hours life span of the led lamps.

    Q2: What about your Pre-sale service and After-sale service?

    A2: For Pre-sale service: We have a professional sales team and professional technical team who are willing to answer your question 24 hours on line. We can offer a set of solution for your project!


    For After-sale service: We can instruct you how to use, adjust the screens, and common maintenance with spare parts.


    Also, we can send engineers to your country if you need.


    Q3: What’s your payment term? How long it takes to delivery?


    A3: We accept T/T and Western Union, For both T/T and Western Union, At least 30% deposit in advance, and the rest 70% before delivery.


    Production time would be about 15-25 days according to your order quantity.

    Q4: What's the control system?

    A4: For synchronous control system: We use Nova, Linsn or Colorlight control system.

    For asynchronous control system: We use Onbon or Xixun control system.

    Q5: How can you ensure the led display product quality?

    A5: We have more than 10-year experience in producing Led Display with good reputation in this industry.

    We would do 24 hours ageing to promise 100% non-dead chips before shipment.
