China factory Transparent LED Scree HD P3.91 , Full Color Outdoor
Advertising led Display Advertising Screen
Parameter description:
| Resolution/mm | 3.91 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 32768dots/square meter |
| Module size/mm | 1000x500 |
| View distance | 4-50m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | 2500cd/square meter |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | 1/8 |
| Frame rate | 60Hz |
| Refresh frequency | 3840Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Maximum power:/square meter | <950W |
| Average power:/square meter | <350W |
| Self-check technology | LED spot self-check, communications check, power check, |
| temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature
protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
Why choose us?
1.Rich experience for more than 10 years;
2.Strict control quality and supervision;
3.Good price for high quality products;
4.Quick delivery time-after receiving your down payment we will
make the delivery right soon;
5.Satisfied after sales service-we will reply you all the questions
in 3 hours;
6.We will provide you the free technical supply;
Description:
* High Degree of Visibility
80% transparent see-through, so it is convenient for people inside
and outside to look-through. The integrated LED lamps are very tiny
and almost invisible from outside of the building.
* Compact Design and Light Weight
almost suitable for any glass wall building.The weight is only
18kg/sqm and minimizes the load to the glass wall.
* Ease of the Installation and Maintenance
No need to change any building structure. The modules can be stuck
to the back of the glass wall by the special glue which presented
by us. It needs only 10 second to install one module. Should any
maintenance occurs, it only requires to do it at the indoor.
* Saving Money in Decoration for the Architecture
Since the LED glass wall makes the vivid decoration and
advertising, it saves other lights to lighting up the building.
* Wide Application
The Glass Wall LED Screen can be applied wherever the glass wall
existed such as commercial building,landmark,architecture, art
center,shopping mall, super market, shain stores etc.
Our cases:
Our Company:
FAQ
1.Q:Are you a factory or trading company?
A:We are a factory,located in Dalang,Longhua District .
2.Q:What kind of payment terms you accept?
A:We accept T/T,Western Union,MoneyGram etc.
3.Q:What's packaging?
A:1.Flight case packaging
2.Wooden case packaging
3.36pcs in one case packaging
4.Customized packaging
4.Q:Does you have CE/ROHS certificates?
A:Yes, we offer the CE & ROHS certificates .
5.Q:What's the shipping method,shipping time?
A:Our products could be shipped by Sea, by Air, and by Express.
by sea:20-40days; by air:5-10days ;by express:3-6days
