Hot Sale in China P5 Curtain LED Display Full Color Energy
Conservation
Introduction of the cabinets:
We have two kinds of cabinets, one is iron cabinet and the other is
die-cast cabinet.
Maybe you will be confused about this, then let me tell you.
Iron cabinet is used for fixed installation and is heavier. You can
use it indoors and outdoors; die-cast cabinet is used for rental
installation and is relatively light,
You can also use it indoors and outdoors, such as wedding parties,
concerts, etc.
Therefore, for indoor use, you should pay attention to brightness,
resolution, and especially
scan mode, because the viewing distance is close and the video
needs to be vivid; for outdoor use,
waterproof is obviously important because of weather and some other
uncertain situations.
Then the application place is also important, for your reference,
if you use it on the road, then
the spacing can be large, which is enough. If you use it for
concerts, then the spacing needs to be relatively small, but not
too small, about 5 mm is fine.
First of all, you should understand 3 points before buying: indoor
or outdoor, fixed or rental, and the picture effect you want. Then
you can tell us these, and we will recommend the most suitable
product for you.
Thank you for your time, waiting for your inquiry online!
Specifications of product:
Indoor P5 LED screen Display | |||||
Resolution/mm | 5 | ||||
Pixel configuration | 1R1G1B | ||||
Pixel density/pixels/m² | 40000/square meter | ||||
Module resolution | 64*32mm | ||||
Module size/mm | 320*160mm | ||||
View distance | 5-100m | ||||
Single point brightness adjust | Can be added | ||||
Single point color adjust | Can be added | ||||
White balance brightness | >1200cd/square meter | ||||
Color temperature | 6500K-9500K | ||||
Horizontal view angle | 120(degrees) | ||||
Vertical view angle | 60(degrees) | ||||
Signal Process bit | 10 or 16bit | ||||
Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
Driving mode | Constant driving current | ||||
Scanning mode | 1/16 | ||||
Fresh rate | 60Hz | ||||
Refresh frequency | >3000Hz | ||||
Control mode | Computer synchronous | ||||
Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
255 steps. No grey loss | |||||
Out of control point | <1/10000 | ||||
Working hours | ≥72hours | ||||
Mean Time Between Failure | >5000hours | ||||
Life time | 100000hours | ||||
Life-all-white(brightness halving) | 50000hours | ||||
Environment temperature range | Operating temperature range: -20-45℃ | ||||
Self-check technology | LED spot self-check, communications check, power check, | ||||
temperature monitor(need customization) | |||||
Remote monitoring | Remote supervision and control, record potential fault, | ||||
send out warning signs to the operators.(need customization) | |||||
Software environment | WindowsNT,Windows1999,WindowsXP | ||||
Luminous point width between centres | Deviation<3% | ||||
Brightness uniformity | <10% | ||||
Waterproof | IP34 | ||||
Color uniformity(chromaticity coordinate) | ±0.003 | ||||
Power supply request | AC85-264V(50Hz-60Hz) | ||||
Contrast | (1000:1) | ||||
System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
Humidity(working) | working:10-95% | ||||
Humidity(storing) | storing:10-95% |
The payment details:
1. We accept T/T, Western Union, 30% in advance, the balance 70%
before delivery.
2. Delivery time (lead time): 12-15 working days after receiving
the deposit.
3. Warranty: The warranty period is 2 years after delivery and free
maintenance.
4. Free Training: You can send engineers with electronic knowledge
to our factory for training. We will provide free training on how
to operate, maintain and repair the LED display.
5. Technical support: We can send engineers to your country for
guidance, but you must help us to apply for visas and pay the
related costs, such as round-trip air tickets, hotels, meals and
other costs after the engineers arrive in your country.
FAQ
Q1: What is the control system? How is it?
A: We use Nova Taurus Series asynchronous control system. Support
cluster play and management. Support APP/Phone/ WIFI/ Ipad/ Laptop/
PC/ Cloud control. It’s very easy and convenient to control.
Q2: Can I have a sample order for led screen?
A: Yes, we welcome sample order to test and check quality. Mixed
samples areacceptable.
Q3:Is it OK to print my logo on product?
A: Yes. Please inform us formally before our production and confirm
the design firstly based on our sample.
Q4: What is your best service?
1: One to one sales engineer to customer responsibility system;
2. Know your project and provide the best solution for it;
3. Track your order and let you know each step and detail of it;
4. Teach you how to install and use the screen;
5. Care the subsequent use of your screen and ensure your after -
sales service be well.
Q5. How about your delivery time?
A: Generally, it will take 7-15 days after receiving your deposit.
The specific delivery time depends on the items and the quantity of
your order.
Q6:How about your Warranty Term?
A: 2-year warranty. Structure design, installation problem, system
problem, how to use the screen…don’t worry, we have professional
after-sale team to solve your any questions after you placed an
order. And your exclusive sales engineer will also help you get
over any problems.
![]() |
