Outdoor Indoor Stage Background Flexible Curved LED Screen HD
Curved Waterproof LED Display Video Wall
About us:
SCXK is a manufacture of producing indoor and outdoor rgb led displays
in China with our own factory,
located in Shenzhen,which is the technical centure of country,also
the transparent is very convenient and cheap.
Every year many businessmen all over the world come here to visit
factories and select the supplier,
and our company already has cooperated with hundreds of
companies,they are from America,Russia,India,Korea,
Kazakhstan,Philippines,England,Canada ect.
We do hope we can make cooperation and give you the better service!
1.LED chip description:Supplied by Nicia of Japan,Epistar of
Taiwan,Nationstar of China and other high configuration.
(All the LED chips are selected strickly,assure the high effect)
2.High quality IC also selected:Normally we use
these-MBI5124/5153/2037/2038/2053/2153,
also if you have requirements of it,we will use the type in your
need.
3.Wide viewing angle 120/160°,good and impressive viewing effect.
4.Popular power supply selection:Meanwell,Chuanglian,E-energy ect.
Detailed descriptions:
| Outdoor P3.91 LED Display Screen |
| Resolution/mm | 3.91 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 65410dots/square meter |
| Module resolution | 64x64 |
| Module size/mm | 250x250 |
| View distance | 4-50m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | 6000cd/square meter |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | 1/8 SCANNING |
| Frame rate | 60Hz |
| Refresh frequency | 1920Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Self-check technology | LED spot self-check, communications check, power check, |
| temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature
protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
Package and shipping:
Carton packing cases for LED modules;
Wooden packing cases for iron cabinet;
Flight packing cases for die-casting aluminum cabinet;
Transparent ways normally three:air,sea and train;but the ending
way is depended on where are you
and how long the shipping time you want,we have our own freight
forwarding,and you also can use yours.
If you have any questions ,just type down and send to me!
