Indoor GOB P1.923 LED Display Panel
Wide Viewing Angle Indoor Full Color LED 246x246mm Module Size
Description:
246x246mm LED module
492x492mm LED panel cabinet
RGB full color LED display system
Kinglight LEDs,G-energy LED driver
Why not choose GOB?
Let me explain a little bit about GOB. GOB stands for glue on board, a recently popular technology that is used for SMD protections by
filling certain glue on the PCB board and form a certain barrier
for the SMDs. It’s clear, and won’t affect the lights of the SMD. I
accidently dropped a couple a LED panels, (tell me I’m not the only
one who did this!) and luckily, they were GOB modules, guess what,
after testing, those panels were just as perfect as always Besides,
the highest protection from the glue, another thing wonderful about
the GOB is that it made the cleaning of the surface even easier, wipe it with
slighting wet cloth. Many people may have concerns about how to repair the bad SMDs?
I’ll say, it’s not rocket science, a technician can do it easily as
repairing other SMDs, just requires a couple of steps of digging
and filling the glue. GOB would be perfect for the pitch options
stars from around 1.667mm or above.
Introduction:
1. Outdoor full color LED large screen series, pixel density is
super high, the picture effect is more high-definition.
2. Cost-effective, to meet your needs for high-definition picture
at the same time also has a good cost-effective, greatly reducing
your investment costs;
3. 3. high efficiency: LED large screen products using ultra-high
brightness low-power drive LED, power savings of more than 20%, PFC
circuit design with temperature control, display control,
brightness control and other technologies, you can achieve the
effect of energy-saving machine;
4. 4. high protection level: unique shell design, IP protection
standards, can be used for outdoor installation. 5. standardized
design: shell, display control, brightness control and other
technologies;
5. standardized design: shell, module and other components adopt
standardized design, good compatibility between different products,
high degree of standardization, providing great convenience for
production and maintenance;
Translated with DeepL.com (free version)
Products Series:
Small pixel
:P1.5--P1.667--P1.875--P1.9--P1.923--P2--P2.5--P2.98--P3--P3.91
Outdoor pixel series
:P3.91--P4--P4.81--P5--P5.95--P6--P6.25--P6.67--P8--P10--P10.66--P16
Indoor pixel
series:P3.91--P4--P4.81--P5--P5.95--P6--P6.25--P7.62--P10--P12.5
Advantages
Special heat dissipation design inside out led chip;
Great heat dissipation ability inside out from Drive IC;
Model cover and cabinet adopted die-casting aluminum material
Improves the heat dissipation effect, and Drive IC is accompanied
with cooling material outside;
Plus the high efficient power supply can decrease heat output;
Specifications :
| outdoor DIP P1.923 |
| Resolution/mm | 1.923 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 270420/m² |
| Module resolution | 128x128 |
| Module size/mm | 246x246mm |
| View distance | 14-300m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >7500cd/㎡ |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | 1/30 SCANNING |
| Frame rate | 60Hz |
| Refresh frequency | >3000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Self-check technology | LED spot self-check, communications check, power check, |
| temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature
protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance
guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including
installation guidance, software operation manual, easy maintenance
manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions,
squares and so on.
Our Company:
FAQ:
Q1: What's the warranty of your LED Display Screen ? A1: We have a 3-year warranty for our led display screen, and
100,000 hours life span of the led lamps. |
Q2: What about your pre-sale service and post-sale service? A2: For pre-sale service: We have a professional sales team and 13
years technical team who are willing to answer your question 24/7.
We can offer a whole complete solution for your project!
For post-sale service: We can instruct you how to use, adjust the
screens, and change the broken modules with spare parts.
Also, we can send technicians to your country to solve problems.
Mostly, our led display will not have big problems within warranty
time! |
Q3: Whats your payment term? How long it takes to delivery? A3: We accept T/T and L/C, For both T/T and L/C, At least 30%
deposit in advance, and the rest 70% before delivery.
Our average Production time is 16 days, after receiving the
deposit. |
Q4: What's the control system? A4: For synchronization control: We use Nova, Linsn Or Colorlight
control system.
For asynchronous control: We use ONBON or XIXUN control system. |
Q5: How can you ensure the led display product quality? A5: Our led display screen quality is our core competence, for 8
years, what we rely on.
We have each standard process to make quality products.
If any quality failures within warranty time, we will refund you . |
Welcome to visit our website and inquire us more info,waiting for
you all the time!!!
