Brand Name : | SCXK |
Model Number : | P1.56 |
Certification : | CE,ROHS,FC,SASO |
Price : | negotiation |
Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability : | 1000 sqm per month |
Delivery Time : | 7 working days |
New 2020 GOB COB high refresh rate over 3840HZ Exhibition LED Screen P1.56 fixed led video panel HD Full Color
GOB Technology Introduction
Pamameter
Pixel Pitch(mm) | 1.56mm |
LED Type | GOB |
LED Configuration | 1R1G1B |
LEDs | SMD1010 |
Refresh Rate(Hz) | ≥3840Hz |
Module Resolution (PXxPX) | 128*96 |
Module Size (mmxmm) | 200mm*150mm |
Max Current | 6A |
Input Voltage | 5V |
Module max power consumption | 6.5W |
Scanning mode | 1/32 |
Horizontal Viewing Angle(Deg) | ≥170(+10/-10) |
Vertical Viewing Angle(Deg) | ≥170(+10/-10) |
Brightness | >1200 CD/m2 |
Grey Scale | >14bit |
Cabinet Resolution(PXxPX) | 384*216 |
Cabinet Size | 400mm*300mm |
Cabinet Density (dot/sqm) | 49152 Dots/m2 |
Malfunction Dot Rate | <0.3% |
Power Supply | DC 5V |
Working Temperature(℃) | -40-60℃ |
Working Humidity | 10%-90% RH |
Lifespan(H) | ≥50,000 |
16:9 Golden Ratio Design, 2k 4k 8k Perfect Display
16:9 cabinet size design, point-to-point matching 2K/4K/8K standard
resolution; front maintenance design, wall-mountable installation,
easy installation and maintenance; automatic brightness adjustment
technology, ensuring viewers in any environment to watch
comfortably; support power and signal redundancy backup to meet the
needs of high security applications.
FAQ
A: Yes, we welcome sample order to test and check quality. Both for module or whole screen.
A:Order less than 100 square meter led time take 15 working days
A: Low MOQ, 1 square meter or a moudle checking is available
A: We mostly accectp FOB train term, but we can help you order and arrange shipping agent. It usually take 20 30 day on sea. a few days for customer clearance
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our
suggestions.
Thirdly customer confirms the design document and places deposit
for formal order.
Fourthly We arrange the production.
![]() |
