Outdoor Waterproof P8 Fixed Advertising Video Screen SMD LED
Display Billboard Out of Home Advertising D
Environmental Advantages1) Keep people safe
2) Improving the quality of life
3) Outdoor LED signs deliver better service
Business Advantages
1) Boadening customer base
2) High-quality images
3) Release content efficiently
4) Energy conservations
5) Environment protected
6) Update your Ad effectively
7) Impact force
8) Diversity
9) Wide angle of view
Product Advantage
1. Application
Widely use in stadiums, advertisement, banks, securities exchange,
stations, shopping malls, postal offices, schools, restaurants,
entertainment, enterprises ,highway etc
2. Market:
North America, South America, Eastern Europe, Southeast Asia,
Africa, Oceania, Mid East, Eastern Asia, Western Europe
3. Price Advantage:
we have the best competitive price at the market, also have the
same even better quality.
4. Quality advantage:
From material to finished product, from design to produce, we
control all steps
5. Service advantage:
Better service at same situation, better cooperation at same
service
Trade Terms
1).Payment: T/T ,ususally 40% prepayment before production, 60%
balance to be paid before delivering,it also change according to
total quantity
2).Production lead time less 20 sqm: 8-15days, more than 50
sqm:30days
3).Sample can be deliveried within 3days
4).Shipping port: Shenzhen, Mainland China
5).Discounts are offered based on order quantities
6).MOQ:1 sqm/1pc
Product Specifications
Module Parameter:
| Pixel pitch | 8mm |
| Pixel configuration | 1R1G1B |
| LED type | 3-in-1 SMD 3535 |
| Module size | 256*128mm |
| Module weight | 310g |
| Module resolution | 32*16 dots |
Cabinet Parameter:
| Cabinet size | 1024*1024*130mm |
| Cabinet material | iron cabinet |
| Cabinet weight | 50kgs |
| Ingress protection | Front/Rear IP65/IP54 |
Whole Screen Parameter| Pixel density | 15625dots/m² |
| Brightness | ≥6300 cd/m² |
| Viewing angle | H≥160° V≥160° |
| Min.viewing distance | 5m |
| Max.power consumption | 1200W/m² |
| Avg.power consumption | 600 W/m² |
| Working voltage | 110~220VAC±15% |
| Interface | HUB75 |
| Colors | 16.7millon colors |
| Gray level | 14-16bits |
| Frame frequency | ≥60frames/s |
| Refresh rate | ≥300Hz |
| MTBF | ≥10000 hours |
| Lifespan | ≥75000 hours |
| Protective function | Over-heat/Over-load /Power-down /Power-leakage /Lightning-protection etc. |
| Operating temperature | -10℃ ~ +40℃ |
| Operating humidity | 10-80% no condensation |
| Storage temperature | -20℃ ~ +60℃ |
| Storage humidity | 10-85% no condensation |
Control System Parameter:
| Video signal (with video processor) | AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP |
| Color temperature | Adjustable by software |
| Brightness level | 256 levels, automatic adjustment by software |
| Control way | Computer, video-synchronous, real-time, off-line, wireless,
internet etc. |
Our case
Our Service
Pre-sales service :
Our team design and make solutions based on different requirements
from different customers, what you think is what we can do.
After-sales services:
1. We provide customer service through Skype, phone or email,
supply you video or drawing to solve problems.
2. We provide remote control service through internet to achieve
real time service, which will short time of solving problems.
3. We provide one professional engineer to one customer to keep
fastly reply.
Installation Service:
1. We provide detailed CAD drawing to customer for preparing metal
structure.
2. We could dispatch our engineer to your place , guide
installation and free training.
3. Special designs have special solutions; we will make perfect
solutions to satisfy all customers' requirements
FAQ
Q1: What`s your payment term? How long it takes to delivery?
A: We accept T/T and L/C, For both T/T and L/C,Our average Production time is 16 days after receiving the deposit.
Q2. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q3: What about your pre-sale service and post-sale service?
A: For pre-sale service: We have a professional sales team and a 8
years technical team who are willing to answer your question 24/7.
We can offer a whole complete solution for your project!
For post-sale service: We can instruct you how to use, adjust the
screens, and change the broken modules with spare parts. Also, we can send technicals to your country to solve problems.
Mostly, our led display will not have big problems within warranty
time!
Q4: What's the control system?
A: We use Colorlight control system,Nova control system,can choose
by customers.
Q5: What's the warranty of your LED Display Screen ?
A: We have a 2-year warranty for our led display screen, and
100,000 hours life span of the led lamps.
Q6. How to proceed an order for led display?
A: Firstly let us know your requirements or application, liking
project size, rental or fixed installation.
Secondly We quote according to your requirements or our
suggestions.
Thirdly customer confirms the order and places deposit for formal
order.
Fourthly We arrange the finished display cabinet.
