P4.8mm rental HD LED display outdoor stage background large screen
LED rental, 3840hz refresh rate
♦ About LED Display
LED display,also called led screen, led video wall, or led sign,
with its unique advantages,has gradually replaced the traditional
billboards, light boxes,etc. LED display advertising has become a
new force in the media industry.
Traditional advertising can only show pictures, But LED display/led
video wall/led screen can perfect combine text, pictures, video,
and sound with high resolution,high brightness and full color! LED
display Advertising screen can easily attract the attention of
pedestrians,and also are easy to remember,which can generate
greater advertising effectiveness.
♦ The features of outdoor rental LED display
1. LED display wide applied in
stadiums,advertisement,banks,securities exchange,stations,shopping
malls,postal
offices,schools,monitoring,restaurants,entertainment,enterprises
etc.
2. Vivid and exact picture, minimum noise, advanced test equipment,
support any pc operation system and play a variety of information
like video, word, flash, music, clock, graph etc.
3. High brightness and support brightness automatically adjustment.
4. Long lifespan, can reach more than 100,000 hours, while the
power consumption is lower than one tenth of lamp or neon;
5. Easy & simple installation interface and user friendly software
to ensure the user friendly interface of the LED display system;
6. Rich LED display engineering experience both in domestic and
international market.
♦ Product specification
| indoor SMD P4.8 |
| Lamp size | 2121 |
| Resolution/mm | 4.8 |
| Pixel configuration | RGB 3 in 1 |
| Pixel density/pixels/m² | 43222/m² |
| Module resolution | 64x64 |
| Module size/mm | 250x250 |
| View distance | ≥3m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >2500cd/㎡ |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 14 bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:5km |
| Driving mode | Constant driving current |
| Scanning mode | 1/13 |
| Frame rate | 60Hz |
| Refresh frequency | >3000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ Storing temperature range:
-30-65℃ |
| Maximum power:/㎡ | <1100W |
| Average power:/㎡ | <280W |
| Self-check technology | LED spot self-check, communications check, power check, temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization) |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature
protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
♦ About us:
Established in 2005, clients cover more than 50 cuntries, Mainly
USA, Europe, dubai, north and mid america, south america, asia. As
a high-tech enterprise integrated with scientific research, design,
production, maintenance, sales and system integration, we have a
professional high-quality technical R & D team,rich experienced
engineers and professional product development and design
engineers,excellent marketing team, pre and after-sales 24 hours
service. Even face with harshest environment,we can carefully
choose different suitable materials and make the best offer.
Small Pixel LED Screen for Clearer Pictures
The Small Pixel LED Display features small pixel modules which
presents clearer and vivid images even in low brightness and dark
days. The display is suitable for various applications including
security monitoring center, scheduling command platform, smart
city, television studio and high-end meetings.
♦ Packaging and shipping
Wooden case or flight case package are available.
Shipping by sea,air or DHL,multiple shipping ways for your choice.
Our team will be forever here to offer you full supports
