    110 - 220VAC P4.81 Outdoor Stage RGB LED Display With 3840Hz Refresh Rate

    Ask Lasest Price
    Brand Name : SCXK
    Model Number : SMD P4.81
    Certification : CB/CE/ROHS/FCC/ISO/UL
    Price : negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 5000 sqm month
    Delivery Time : 7-10 working days
    • Product Details
    • Company Profile

    110 - 220VAC P4.81 Outdoor Stage RGB LED Display With 3840Hz Refresh Rate

    110-220 VAC P4.81 outdoor stage LED screen indoor advertising panel wide angle, 3840hz refresh rate


    Product features
    1. Excellent effect: Using dynamic scanning technology, the picture is stable, no noise, the image effect is clear, the animation effect is vivid and diverse, and the video effect is smooth and realistic;
    2, rich in content: can display text, graphics, images, animation, video information;
    3, flexible mode: the user can arbitrarily arrange the display mode;
    4, the cabinet customization: the cabinet supports customized size;
    5, excellent viewing angle: both horizontal and vertical have a large viewing angle, which is suitable for environments with wide horizontal distribution and large height difference;
    6. High reliability: using distributed scanning technology and modular design technology, reliability and stability are higher;
    7, quality assurance: the use of imported luminescent materials, high-quality IC chips, noise-free high-power power supply; tensile and shockproof, 10 years of long life;
    8, easy maintenance: modular design, easy installation and maintenance.

    Product specification

    SMD P4.81
    Lamp size2121
    Resolution/mm4.81
    Pixel configurationRGB 3 in 1
    Pixel density/pixels/m²64510/m²
    Module resolution64x64
    Module size/mm250x250
    View distance≥2m
    Single point brightness adjustCan be added
    Single point color adjustCan be added
    White balance brightness>8000cd/㎡
    Color temperature6500K-9500K
    Horizontal view angle120(degrees)
    Vertical view angle60(degrees)
    Signal Process bit10 or 14 bit
    Grey process1024x1024x1024 16834x16834x16834 65536x65536x65536
    Control distancesInternet cable:100m, multimembrane:500m, monofilm:5km
    Driving modeConstant driving current
    Scanning mode1/8
    Frame rate60Hz
    Refresh frequency>4200Hz
    Control modeComputer synchronous
    Brightness adjusted rangeManual, automatic operation, stepless continuous adjusted
    255 steps. No grey loss
    Out of control point<1/10000
    Working hours≥72hours
    Mean Time Between Failure>5000hours
    Life time100000hours
    Life-all-white(brightness halving)50000hours
    Environment temperature rangeOperating temperature range: -20-45℃ Storing temperature range: -30-65℃
    Maximum power:/㎡<1000W
    Average power:/㎡<280W
    Self-check technologyLED spot self-check, communications check, power check,
    temperature monitor(need customization)
    Remote monitoringRemote supervision and control, record potential fault,
    send out warning signs to the operators.(need customization)
    Software environmentWindowsNT,Windows1999,WindowsXP
    Luminous point width between centresDeviation<3%
    Brightness uniformity<10%
    Color uniformity(chromaticity coordinate)±0.003
    Power supply requestAC85-264V(50Hz-60Hz)
    Contrast(1000:1)
    System protectionMoistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
    Humidity(working)working:10-95%
    Humidity(storing)storing:10-95%


    Product Overviews

    ItemsIndoor Led display:
    P2, P2.5, P3, P3.91, P4,P4.81, P5, P6, P7.62, P10
    Outdoor Led display:
    P4, P4.81, P5, P6, P8, P10, P12, P16,P20,P25,P31.25
    Materialsteel,aluminum ,die casting aluminum
    Payment
    terms
    30% deposit before production, 70% balance before shipping
    T/T
    Western Union
    Packing:Standard Export Carton with fully Polyfoam or Pearl Wool
    Flight case;
    Anti-shaking wooden case
    Shipping:5 to 7 working days upon receiving deposit payment
    After-Sales-Service:Lifetime with professional engineer support for free.
    Within 5 year, supply spare parts for free if has quality problem
    ( not by man-made damage)
    Using RangeShopping mall,bank,bus station, train station,
    center of downtown, airport, school, factory, bus, taxi,and so on.


    Production process:
    1) Incoming Inspection→2) SMD→3) Plug-in
    →4) Wave Soldering→5) After Welding→6) Testing
    →7) Semi Finished Aging→8) Module Assembly
    →9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing
    Features
    1. Seamless --- precision cabinet, light weight and more durable.
    2. Quality LEDs --- with wide viewing angle to ensure vivid and sharp images and video.
    3. High refresh rate and high gray scale --- to ensure color consistency and better images
    Packaging and shipping
    Wooden case or flight case package are available.
    Shipping by sea,air or DHL,multiple shipping ways for your choice.


    Our team will be forever here to offer you full supports
