SCX LED High refresh rate Outdoor fixed installation P8 LED display
screen buildingg advertising billboard
Led video wall screen P8 SMD outdoor LED display Outdoor Billboard
Screen
1. The first level LED chip from Taiwan Epistar
2. With pure golden wire connection in LED
3. Grand A row material for module frame and mask
4 layers PCB and copper plating thickness > 18mil
5. Stainless steel screws when assembly
6. Disassembly and assembly are quick and easy
7. 3 to 5 years warranty
8 .Energy-saving 60% : driving with low frequency current,
heat-dissipated roller fans with automatic temperature-controlling
device.
9 .Life time >11 years;
Established in 2005,Shenzhen Shichuangxike Electronics Co.,Ltd has been focusing on the international market to realize the global
strategic layout. Relying on the strong technical strength, the
advanced production management system, the complete operating
programs and our international business team, we successfully set
up a base gathering the abilities of R & D, production and sales in
Shenzhen.
| HD outdoor full color P8 Led display specification |
| LED Module | Pixel Pitch | 8mm |
| Module Size | 256mmx128mm |
| Module Resolution | 32*16dots |
| LED Cabinet | Cabinet Size | 512mmX512mm |
| Cabinet Resolution | 128pixels *128pixels |
| Cabinets Material | die casting aluminum |
| LED Display | Pixel Density | 15625pixels/sq.m |
| Drive IC | MBI5024 |
| Brightness | >7500cd/sqm |
| Viewing Angle | 110°(Horizontal),50°(Vertical) |
| Best Viewing Distance | 4m~200m |
| Max Power Consumption | 600 w/sq.m |
| Average Consumption | 300 w/sq.m |
| Weight | 22Kgs/sq.m |
| Refresh Rate | 3500hz |
| Input Voltage | AC220V/50H or AC110V/60H |
| Output Voltage | DC5V,40A |
| Grey Scale Levels | 1024 |
| Display Colors | R(1024) x G(1024) x B(1024) |
| Protection Level | IP65 |
| Failure leds | less than 0.0003 |
| Drive Mode | 1/4 scaning |
Case
FAQ
Q1: What's the warranty of your LED Display screen?A1: We have a
2-vear warranty for our led display screen, and 100,000 hourslife
span of the led lamps .
Q2: What about your pre-sale service and post-sale service?
A2: For pre-sale service: we have a professional sales team and a 8
vears technical team who are willing to answer your question 24/7.
We can offer a whole complete solution for your project!For
post-sale service: We can instruct you how to use, adiust the
screens, and change the broken modules with spare.parts.Also, we
can send technicians to your country to solve problems. Mostly our
led display will not have big problems within warranty time!
Q3: Whats your payment term? How long it takes to delivery?
A3: We accept T/T and L/C, For both T/T and LC, At least 30%
deposit in advance, and the rest 70% before delivery Our average
Production time is 7-15 days, after receiving the deposit .
Q4: What's the control system?
A4: For synchronization control: We use Nova, Linsn Or Colorlight
control system For asynchronous control: we use Onbon. or Xixun
control system.
Q5: How can you ensure the led display product quality?
A5: Our led display screen quality is our core competence, for 10
years, what we rely on.We have each standard process to make
quality productsIr any quality failures within warranty time,
Competitive Advantage:
1. 2 years’ warranty with free repair service
2. 24/7 Hours online Remote Support
3. Solution and PCB design
4. Free factory training
5. On site installation instruction and regular inspection
6, Small order accepted.
Payment and delivery
1) T/T, 30% deposit, 70% before shippment.
2) 100% Western Union in advance.
