    P4 SMD2121 p4 led panel RGB full color led display module,indoor LED panel, 1/16 scan 256*128mm, text, pictures, video s

    Ask Lasest Price
    Brand Name : SCX
    Model Number : SMD P4
    Certification : CE/ROHS/FCC/ISO/UL
    Price : negotiation
    Payment Terms : L/C, T/T, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 6500 sqm month
    Delivery Time : 5-12 working days
    • Product Details
    • Company Profile

    P4 SMD2121 p4 led panel RGB full color led display module,indoor LED panel, 1/16 scan 256*128mm, text, pictures, video s

    P4 512*512mm SMD2121 Indoor LED Display Screen Die Casting Aluminum Cabinet Video Wall Rental LED Advertising Billboard


    indoor SMD P4
    Lamp size2121
    Resolution/mm4
    Pixel configurationRGB 3 in 1
    Pixel density/pixels/m²62500/m²
    Module resolution32x32
    Module size/mm256x128
    View distance≥4m
    Single point brightness adjustCan be added
    Single point color adjustCan be added
    White balance brightness>1800cd/㎡
    Color temperature6500K-9500K
    Horizontal view angle120(degrees)
    Vertical view angle120(degrees)
    Signal Process bit10 or 14 bit
    Grey process1024x1024x1024 16834x16834x16834 65536x65536x65536
    Control distancesInternet cable:100m, multimembrane:500m, monofilm:5km
    Driving modeConstant driving current
    Scanning mode1/16
    Frame rate60Hz
    Refresh frequency>1200Hz
    Control modeComputer synchronous
    Brightness adjusted range

    Manual, automatic operation, stepless continuous adjusted
    255 steps. No grey loss

    Out of control point<1/10000
    Working hours≥72hours
    Mean Time Between Failure>5000hours
    Life time100000hours
    Life-all-white(brightness halving)50000hours
    Environment temperature rangeOperating temperature range: -20-45℃ Storing temperature range: -30-65℃
    Maximum power:/㎡<1100W
    Average power:/㎡<280W
    Self-check technology

    LED spot self-check, communications check, power check,
    temperature monitor(need customization)

    Remote monitoring

    Remote supervision and control, record potential fault,
    send out warning signs to the operators.(need customization)

    Software environmentWindowsNT,Windows1999,WindowsXP
    Luminous point width between centresDeviation<3%
    Brightness uniformity<10%
    Color uniformity(chromaticity coordinate)±0.003
    Power supply requestAC85-264V(50Hz-60Hz)
    Contrast(1000:1)
    System protectionMoistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
    Humidity(working)working:10-95%
    Humidity(storing)storing:10-95%

    P4 SMD2121 p4 led panel RGB full color led display module,indoor LED panel, 1/16 scan 256*128mm, text, pictures, video sP4 SMD2121 p4 led panel RGB full color led display module,indoor LED panel, 1/16 scan 256*128mm, text, pictures, video sP4 SMD2121 p4 led panel RGB full color led display module,indoor LED panel, 1/16 scan 256*128mm, text, pictures, video s

    1. High definition small pixel pitch, suitable for indoor short distance vision
    2.Ultra slim well-formed cabinet;

    3. Easier for insallation and maintenance

    4. SMD 3-in-i technology, big visual angel, no deformation of pictures

    5.Fast heat dissipation

    6. Support fixed and rental movable led display

    7. True color high definition HD video display.

    8. Different cabinet style for choice, rental alumnium or customized cabinet. With your logo printed on the cabinets.


    ♦ Production process:
    1) Incoming Inspection→2) SMD→3) Plug-in
    →4) Wave Soldering→5) After Welding→6) Testing
    →7) Semi Finished Aging→8) Module Assembly
    →9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing

    ♦ Packaging and shipping
    Wooden case or flight case package are available.


    Trade info

    1).Trade terms: FOB,CIF,EXW

    2).Payment terms: T/T ,Western Union, Paypal, Escrow, Moneygram

    3) Payment condition: T/T ,30% deposit before production, 70% balance before delivery

    4).Production lead time less 20 sqm: 8-15days, more than 50 sqm:30days. Sample can be deliveried within 3days
    5).Shipping: by sea,by air and by express delivery
    6).Shipping port: Shenzhen, Mainland China


    FAQ


    1. How long could i receive the inquiry reply ?
    A: You will get a reply within 12 hours

    2.How to proceed an order for led display?
    A:Firstly let us know your requirements or application
    Secondly we quote according to your requirements or our suggestions.
    Thurdly customer confirms the design document and places deposit for formal order.
    Fourthly we arrange the productio

    3.What kind of led display do you offer ?
    A: Different product offer different time frame warranty, but all product here we offer 2 year at least warranty

    4.How long will it take to deliver goods ?
    A: We will start preparing goods when we get your bank receipt. The package will be shipped out in 1-2 working days after we get your payment5.How is the after sales service ?
    A: We have a professional team which is in all around the world , also a service hot-line dealing with your complains and feedback.We also offer 24-hour online service to help you solving problems
