    P6 HD Full Color Taxi Top RGB LED Display Easy To Install With WIFI 4G Control

    Ask Lasest Price
    Brand Name : SCXK
    Model Number : SMD P6
    Certification : CB/CE/ROHS/FCC/ISO/UL
    Price : negotiation
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 5000 sqm month
    Delivery Time : 7-10 working days
    • Product Details
    • Company Profile

    P6 HD Full Color Taxi Top RGB LED Display Easy To Install With WIFI 4G Control

    P6mm HD full color taxi top LED signage display with WIFI 4G control, easy to install

    ♦ Operating Voltage DC12V

    -- Power consumption : Max:800W Average:300W
    -- Operating temperature : —20℃~+50℃
    -- Operating humidity : 10%—95%RH
    -- Life time : ≥100,000hours
    -- MTBF : 5,000 hours
    -- Frame frequency : >60 Hz/s
    -- Operating system : Windows 2000 / Windows Xp / Windows 7


    ♦ Feature
    1. The first level LED chip from Taiwan Epistar
    2. With pure golden wire connection in LED
    3. Grand A row material for module frame and mask

    4. 4 layers PCB and copper plating thickness > 18mil
    5. Stainless steel screws when assembly
    6. Disassembly and assembly are quick and easy
    7. 3 to 5 years warranty

    8 .Energy-saving 60% : driving with low frequency current, heat-dissipated roller fans with automatic temperature-controlling device.
    9 .Life time >11 years;

    ♦ Product specification

    Lamp size2727
    Resolution/mm6
    Pixel configurationRGB 3 in 1
    Pixel density/pixels/m²27778/m²
    Module resolution32*32
    Module size/mm192*192MM
    View distance≥4m
    Single point brightness adjustCan be added
    Single point color adjustCan be added
    White balance brightness>8000cd/㎡
    Color temperature6500K-9500K
    Horizontal view angle120(degrees)
    Vertical view angle60(degrees)
    Signal Process bit10 or 14 bit
    Grey process1024x1024x1024 16834x16834x16834 65536x65536x65536
    Control distancesInternet cable:100m, multimembrane:500m, monofilm:5km
    Driving modeConstant driving current
    Scanning modeconstant driving static
    Frame rate60Hz
    Refresh frequency>2500Hz
    Control modeComputer synchronous
    Brightness adjusted range

    Manual, automatic operation, stepless continuous adjusted
    255 steps. No grey loss

    Out of control point<1/10000
    Working hours≥72hours
    Mean Time Between Failure>5000hours
    Life time100000hours
    Life-all-white(brightness halving)50000hours
    Environment temperature rangeOperating temperature range: -20-45℃ Storing temperature range: -30-65℃
    Maximum power:/㎡<800W
    Average power:/㎡<300W
    Self-check technology

    LED spot self-check, communications check, power check,
    temperature monitor(need customization)

    Remote monitoring

    Remote supervision and control, record potential fault,
    send out warning signs to the operators.(need customization)

    Software environmentWindowsNT,Windows1999,WindowsXP
    Luminous point width between centresDeviation<3%
    Brightness uniformity<10%
    Color uniformity(chromaticity coordinate)±0.003
    Power supply requestAC85-264V(50Hz-60Hz)
    Contrast(1000:1)
    System protectionMoistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration
    Humidity(working)working:10-95%
    Humidity(storing)storing:10-95%


    P6mm HD Full Color Taxi car Top LED sign Display With WIFI 4G control
    ♦ Production process:
    1) Incoming Inspection→2) SMD→3) Plug-in
    →4) Wave Soldering→5) After Welding→6) Testing
    →7) Semi Finished Aging→8) Module Assembly
    →9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing

    ♦ Packaging and shipping
    Wooden case or flight case package are available.
    Shipping by sea,air or DHL,multiple shipping ways for your choice.

    Fast Delivery
    Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
    inventory will be used to maintain your uninterrupted supply of the products.

    Perfect Service
    Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
    you.
    After-sales:We will track the products usage and then constantly perfect our products.

    Our team will be forever here to offer you full supports
