indoor p3 SMD LED display module 1/16scan With 64 x 64 Resolution

Ask Lasest Price
Brand Name :	SCXK
Model Number :	P3
Certification :	CE/ROHS/FCC/ISO/UL
Price :	negotiation
Payment Terms :	T/T or western Union
Supply Ability :	5000sqm per month
Delivery Time :	7-10 working days after receive your payment

Add to Cart

Product Details
Company Profile

indoor p3 SMD LED display module 1/16scan With 64 x 64 Resolution

Product Features
1) Reliable quality, advanced and mature technology, compliant with industrial standards and technology developing trend.
2) Good heat emission, water proof and stable performance
3) Audio and video interface of the system can offer vivid, complete and high quality LED display to TV broadcasting
signal
4) High resolution and definition of screen image, clear and non-flash screen image.
5) Supports video and radio frequency input, special structure can be freely assembled.

Specification

Item	Technical Specification
Pixel	Pixel pitch: 3mm
	Pixel configuration: 1R1G1B
	Brightness: Red: 600mcd Green: 2300mcd Blue: 500mcd
	Wave length: Red: 625±2nm Green: 525±2nm Blue: 470±2nm
Module	Module size: 192mmx192mm
Module	Module resolution:64x64pixels
Cabinet	Cabinet resolution:36864pixels
	Cabinet material: Steel
	Gross weight: 15kg
	Module quantity: 3*3=9pcs
	Cabinet size: 576mm*576mm
	Power consumption : Max.:1000W/m² Average: 400W/m²
Screen parameter	Drive method: 1/16 scan
	Brightness: 2000cd/m²
	IC driver: MBI 5024
	Density: 111111pixel/m²
	Whole display flatness: ≤ 1mm juncture
	Best view distance: ≥ 3m
	Viewing angle: Horizontal: 120° Vertical: 120°
	Humidity(RH): ≤ 90~95%
	Working temperature: from -20°C~ +50°C
	Working voltage: AC220V/110V±20%
	Refresh frequency: ≥ 300Hz(Linsn)
	Frame rate: ≥ 540Hz
	Protection grade: IP54
	MTBF: More than 10000hrs
	Life time: 100,000 hrs
Control system	Control system: Linsn
	Signal interface: DVI
	Communication distance: The shielded twisted-pair cable transmission distance for 100 meters, the biggest up to 140 m. Multimode fiber of up to 500 meters, the single-mode optical fiber to 20 kilometers
	Systems operating platforms :XP,WINDOWS(WIN95,WIN98,WIN2000)
	Input Signal:RF,S-VIDEO,RGBTV,YUT,YC,COMPOSITION
	Image adjustment:contrast, tonal, the color saturation, gray calibration coefficient, color range, image variable times, etc
	Life span:100,000 hours
	Out-of Control rate:0.0001
	Control system:Synchronized
	Operating Environment Temperature :-20℃—65℃ Optional

Outdoor LED Display series :
1.Automatic brightness control,super processing ability,strong colour restoration.
2.Support various interfaces and signal sources.
3.Advanced digital control technology, excellent effect.
4.High brightness,even in direct,full-on sunlight to ensure you attract more audience to get short ROI of your full color outdoor led display screen's investment.
5.Antiseptic and durable, can be used outdoor in all weather.
LED module has easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display system.
With full aluminum alloy structure for light weight and waterproof advantages, HJY outdoor led display is an perfect external multimedia LED display system designed for changeable and adverse outdoor environment.

Indoor LED Display series :
The indoor led screen uses high-quality LED, which has high efficiency luminescence,decreased attenuation of brightness,high stability and reliability. Super uniformity in color. Low-budget, high pixel density,more vivid and stable pictures(No Flickering). The ultra-slim and ultra-light weight structure of indoor full color led display,increased design opportunities and lower transportation costs. SMD technology takes super wide viewing angle for the LED display; better color performance,higher contrast ratio and higher refresh rate. The super thin rental indoor led display features low weight,special rigging system for simplified service,hassle-free mounting, easy configuration and maintenance,and several other enhancements that are unmatched in the industry.

The epistar Led chip. with SMD and DIP Technology .

we adopt the epistar led chip from Taiwan,DIP and SMD led display module will be available

The wire or wireless controll system are available .( 4g and wifi controll will be welcome)

Payment and delivery

1) T/T, 30% deposit, 70% before shippment.
2) 100% Western Union in advance.

♦ Why choose us:
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.

Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.

Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.

Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.

♦ FAQ

What kind of payment terms you can accept ?
We can accept T/T and Western Union.

What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of
our products continuity.

What is your delivery time ?
Within 7-35 days according to your area and quantity.

Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure
our led display’s competitiveness.
