Lightweight Outdoor Full Color LED Display Waterproof PH8 Pixel
Pitch 8mm outdoor advertising led display screen
Welcome to Shenzhen Shichuangxinke Electronic Co.,ltd,we are
manufacturer of kinds of led displays with 12 years experience.over
these past years,many types of led display had supplied to our
clients such as indoorhigh definition small pixel pitch led screen
and otdoor super waterproof led products ect. our products win a
good reputation from our clients.and we got more and more oversea
customers .
We have 12-year design experience of offering solution, installation, and after-sales service, etc.
According to different environment conditions, too cold temperature
till -40℃ or very hot temperature up to +55℃, we carefully choose different suitable materials and make the
best offer for every customer. It differs in cables, LED lamps,
plastic masks, waterproof materials, IC, etc. Faced with a variery
of requirements, We offer 24-hour all- direction online service.
led screen feature
1. First-class LED chip:
Supplied by Nichia of Japan & other high strictly selected LED chip
to ensure the long lifetime and high brightness of our LED display
screen system
2. High Contrast ratio: 4000:1
Which is a very high level to ensure a vivid image of our LED
display screen system.
3.Wide application field & short ROI time:
commercial advertising LED display screen, Stadium perimeter LED
display screen, Mobile trailer LED display screen for mobile
media,floor tile screen ect.
shopping mall LED display screen for logo showing, bank&stock
exchange LED display screen for rates showing, train & bus station
LED display screen
air port LED display screen, telecommunication LED display screen
system for information showing and instruction .
4. Clear vivid image quality:
Even in direct full-on sunlight to ensure you attract more audience
to get short ROI of your LED display screen's investment.
| LED Lamps | Type | SMD3528(High Brightness LEDs) |
| LED Standard | Real Pixel(1R1G1B). |
| LED Module | Pixel Pitch | 8mm |
| Module Size | 256mx128m |
| Module Resolution | 32*16dots |
| LED Cabinet | Cabinet Size | 768mmX768mm |
| Cabinet Resolution | 96pixels *96pixels |
| Cabinets Material | Iron steel cabinet |
| LED Display | Pixel Density | 15625pixels/sq.m |
| Drive IC | MBI5024 |
| Power Supply | Series connection |
| Brightness | >2500cd/sqm |
| Display Color | 16.7million |
| Best Viewing Distance | 3m~200m |
| Max Power Consumption | 600 w/sq.m |
| Weight | 35Kgs/sq.m |
| Refresh Rate | 3000hz |
| Drive Mode | 1/4 scaning |
| Control System | Control method | Synchronization & Asynchronization |
| Software | LED Studio (LINSN) |
The epistar Led chip. with SMD and DIP Technology .
we adopt the epistar led chip from Taiwan,DIP and SMD led display
module will be available
Methods for Quality Assurance
a. Aging
1. 100% fully test Condition: 72 hours with 256 gray level
b. Vibration Testing
Condition: 3-5 min up and down in 5mm range
The package and shippment
we can receive all kinds of transportation. and the shippment term.
FOB and CIF. EXW and so on.
we can choose the best shippment which is convenient to you!
SCXK group can give you the short delivery time and With the large
production ability ,
you can feel free about this . By air ,by train, by sea?
Factory Equipment
Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Re flow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection
(AOI) Equipment
♦ Why choose us:
Continues Quality
With more than 10 years experience in led display
producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products
continuous quality.
Competitive Price
With large scale production capacity and professional production
technology,our company have built
effective modular production.We always stick to promote the
technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill
it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the
products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and
we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly
perfect our products.
♦ FAQ
What kind of payment terms you can accept ?
We can accept T/T and Western Union.
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection
before shipment ensure the quality of
our products continuity.
What is your delivery time ?
Within 7-35 days according to your area and quantity.
Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and
professional production ensure
our led display’s competitiveness.
