High definition advetising led SMD P1.25 P1.5625 P1.667 P1.875 full
color indoor LED Display
Advertising Led Screens Features
1. LEDs. we select super led tips with high brightness, broad viewing
angle(H140degree, V140degree), all the LEDs are ageing for 72 hours
before assembly,
when in modules, also aging for 72 hours, after assembly into a
screen, still aging 72 hours. so the final LEDs are aging at least
for 216 hours, up to 9 days.
2. Modules. we use 2R1G1B pixel configuration to realise high brightness. you
may find some lower price suppliers but also same brightness. if
you note,
maybe they use is 1R1G1B, in this case, can cut down much cost but
also cut down the life of the display. why? because to reach the
same brightness,
1R need more current, well for 2R display, each R just need half
current. This just like one man and a team to take a burden, A man
just can undertake,
but two more easily. and our modules case is PVC, which is more durable and have a stronger ability in bask,
anti-ultraviolet and Difficult to deformation
than Plastic ones.
3. Cabinets. they are used in galvanized steel, anti-salt, anticorrosive and
waterproof.
4. Screen. use state-of-the-art LED drive IC-MBI5026, brightness can up to
8000cd/m2, live color video and vivid image with 256 grey level.
for outdoor led displays, all of them are IP 65 and designed to
withstand harsh environmental conditions, such as sun glare, heat,
cold, and humidity.
you can see more details in the quotation.
5. Packing: anti-shaking wooden case, which is lighter than normal wooden case
but more protective to the goods.
Advertising Led Screen Parameters
| |
| Dimension | (W)200mm*150mm(H) |
Pixel pitch | 1.25mm |
Pixel configuration | 1R1G1B |
LED specification | SMD1010 |
Pixel resolution | (W)160*120(H) |
Average power | 25W |
Panel weigth | 0.35 |
| Dimension | 400*300*85mm |
Quantity of panel | 4PCS |
Working temperature | -20--+60 |
Best viewing distance | 1-30M |
Best viewing angle | 170/120 |
Panel power supply | 5V60A |
Screen power supply | 220VAC/50Hz+_10% |
Max power | 1250W/sqm |
Average power | 500W/sqm |
| Driving device | 2053Constant current drive |
Drive type | 1/20S |
Refresh frequency | 2880HZ/S |
Display color | 4096*4096*4096 |
Brightness | 400-800mcd/sqm |
Life span | 100000Hours |
Communication distance | <100M |
Advertising Led Screens use
Advertising Led Screen Packing
Our service and warranty
1.We guarantee all our screens, modules, spare parts for TWO years.
2.We provide technology training for free, which contains the
operation and maintenance training of the LED screens in the
factory.
3.After warranty , we also can offer you the parts for replacement
at our bottom price.
4.After sales, if you have any problem about our product, you can
inform us by Email, we will reply you at once when we get it and
offer you a good solution
to solve the problem.
5.We also could solve problems for you until it recovers well by
remote control.
FAQ
Q1. How could I buy the products I need if there is no price in the
website?
You can send your inquiry to us about the products you need,our
sales will reply you within 24 hours to help you make the order.
Q2. How long could I get reply of my inquiry?
You will get a reply within 24 hours.
Q3. What kind of warranty do you offer?
all product here we offer 3 year at least warranty.
Q4. How is the after sales service?
We have a professional team which is in charge of after-sales
service, also a service hot-line dealing with your complains and
feedback.We also offer 24-hour online service to help you solving
problems.
Q5. What kind of payment methods do you have As a manufacturer?
We take T/T and Cash as payment terms
Q6. How long will it take to deliver goods?
We will start preparing goods when we get your bank receipt. The
package will be shipped out in 1-2 working days after we get your
payment.
Q7. What kind of packaging you offer?
During the packaging process, preventive measures will be taken by
us to assure that the goods are in a good condition during storage
and delivery.
