Outdoor Large Stadium LED Display Screen Live Broadcast Match P6 500cd/m2 Brightness

Shenzhen ShiXin Display Technology Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Outdoor Large Stadium LED Display Screen Live Broadcast Match P6 500cd/m2 Brightness from wholesalers

    Buy cheap Outdoor Large Stadium LED Display Screen Live Broadcast Match P6 500cd/m2 Brightness from wholesalers
    • Buy cheap Outdoor Large Stadium LED Display Screen Live Broadcast Match P6 500cd/m2 Brightness from wholesalers
    • Buy cheap Outdoor Large Stadium LED Display Screen Live Broadcast Match P6 500cd/m2 Brightness from wholesalers

    Outdoor Large Stadium LED Display Screen Live Broadcast Match P6 500cd/m2 Brightness

    Ask Lasest Price
    Brand Name : SCXK
    Model Number : P6
    Certification : CE/ROHS/FCC/ISO/UL
    Price : negotiation
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 5000sqm per month
    • Product Details
    • Company Profile

    Outdoor Large Stadium LED Display Screen Live Broadcast Match P6 500cd/m2 Brightness

    Outdoor Large Stadium LED Display Screen to Live Broadcast Match P6 LED Screen


    Product Features
    1) Reliable quality, advanced and mature technology, compliant with industrial standards and technology developing trend.
    2) Good heat emission, water proof and stable performance.
    3) Audio and video interface of the system can offer vivid, complete and high quality LED display to TV broadcasting signal.
    4) High resolution and definition of screen image, clear and non-flash screen image.
    5) Supports video and radio frequency input, special structure can be freely assembled.

    Module Parameter

    Pixel pitch6mm
    Pixel configuration1R1G1B
    LED type3-in-1 SMD 3535
    Module size192x192mm
    LED lampKingLight or Nationstar
    Module resolution32x32dots
    Module quantity per cabinet25pcs


    Cabinet Parameter

    Cabinet size960x960mm
    Cabinet materialIroned steel cabinet
    Cabinet weight32.5kg
    Ingress protectionFront/Rear IP65/IP54


    Whole Screen Parameter

    Pixel density27778dots/m²
    Brightness≥6500 cd/m²
    Viewing angleH≥120° V≥120°
    Min.viewing distance4m
    Max.power consumption900W/m²
    Avg.power consumption350 W/m²
    Working voltage110~220VAC±15%
    InterfaceHUB75
    Colors16.7millon colors
    Gray level14-16bits
    Frame frequency≥60frames/s
    Refresh rate≥600Hz
    MTBF≥10000 hours
    Lifespan≥50000 hours
    Protective functionOver-heat/Over-load /Power-down /Power-leakage
    /Lightning-protection etc.
    Operating temperature-10℃ ~ +40℃
    Operating humidity10-80% no condensation
    Storage temperature-20℃ ~ +60℃
    Storage humidity10-85% no condensation


    Control System Parameter

    Video signal (with video processor)AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP
    Color temperatureAdjustable by software
    Brightness level256 levels, automatic adjustment by software
    Control wayComputer, video-synchronous, real-time, off-line, wireless, internet etc.


    Cabinet detials


    Product item
    Many other hot product, welcome to visit our company!


    Company profile

    Certificate

    Packaging and shipping
    Shipping by sea,air or DHL,multiple shipping ways for your choice.

    Our service


    Warranty
    1.We guaratee all our display, modules, spare parts for TWO years.
    2.We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory.
    3.After warranty, we also can offer you the parts for replacement at our bottom price.
    4.After sales, if you have any problem about our product, you can inform us by E-mail, we will reply you at once
    when we get it and offer you a good solution to solve the problem.
    5.We also could solve problems for you antil it recovers well by remote control!
    Delivery time
    1.Delivery time, Accompalish manufacturing within 25 days after receiving the deposit.
    2.Before Delivery, we will test the display , and keep it light up for 72 hours, and check all the parts of the display to confirm it is OK for delivery.
    Installation
    1.We can assist the training and technical support for the customer in the factory, if the customer require so.
    2.We could send our engineer to guide the installation to you. But the relavant cost should be paid by your esteemed company.
    3.Our technicians will offer CAD Drawing to show how to install the LED Display rightly and fast, of course, if you need
