Outdoor Multi Screen P6 Rental LED Display 32*32 Resolution
Aluminum SMD
Competitive advantages:
1. P6 SMD outdoor full color LED display screen has uniform
brightness and color;
2. P6 LED full color screen use full black LED chips;
3. indoor full color LED video screen with contrast ratio up to
1000:1, which can truly present the color of the content;
4. 4. adopts Sum driver IC, which can realize high refresh rate and
high grayscale level. 5;
5. Horizontal and vertical viewing angles of 140 degrees. 6;
6. the high resolution of the P6 LED display makes it suitable for
indoor rental events where high quality presentations are required.
Large size indoor LED screen at low cost;
Short details:
| Resolution/mm | 6 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 27778/square meter |
| Module resolution | 32x32 |
| Module size/mm | 192x192 |
| View distance | 9-500m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >7500cd/square meter |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | static full color |
| Frame rate | 60Hz |
| Refresh frequency | >3000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Maximum power:/square meter | <950W |
| Average power:/square meter | <350W |
| Self-check technology | LED spot self-check, communications check, power check, |
| temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature
protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
Spare parts warranty period Configuration Guidelines:
(1) Adequacy: matching with specific equipment, spare parts
configuration is sufficient to ensure that the first time in the
equipment failure to replace;
(2) Necessity: on the basis of previous maintenance experience, we
configure spare parts are the key parts of the equipment, so as to
ensure the economy of the configuration;
(3) Economy and practicality: In order to deal with faults in the
shortest possible time, the spare parts we configure are complete
modules or units, and through our training, the owners can easily
replace the spare parts, thus ensuring the normal operation of the
system.
Our services:
1.Quick delivery after receiving your payment.
2.Provide free tachnical support.
3.Reply fof your inquiry within 4 hours.
4.Warranty for 3-5 years.
During the guarantee time,any problems of machine we provide free
help.
And the products we send you promise the whole new and not the
second hand.
If any questions,just contact us,we'll be here all the time!!!
Welcome to inquire us for more details!!!
