High Resolution P6.67 Outdoor Curtain LED Display IP65 320*160
Module SMD
Our remarks:
1.Price terms: EXW
2.Payment terms: 30% advance payment by T/T, the balance 70% to be
paid before delivery.
3.Delivery time (delivery period): 12-15 working days after
receiving the advance payment.
4.Packing: wooden box and flight box, it is up to you.
5.Warranty: free repair warranty within 2 years after delivery.
6.Free training: you can send engineers with electronic knowledge
to our factory for training. We will provide free training on how
to run, maintain and repair LED display screens.
7.Technical support: we can send engineers to your city for
guidance, but you have to help us get a visa, and pay related
expenses, such as round-trip air tickets, hotels, meals, etc. When
our engineers arrive in your city, you also need to pay our
engineers $100.00/day/person.
Specifications :
| outdoor P6.67 LED Display |
| Resolution/mm | 6.67 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 22478/square meter |
| Module resolution | 48x24 |
| Module size/mm | 320x160mm |
| View distance | 14-300m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >7500cd/square meter |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | 1/8 SCANNING |
| Frame rate | 60Hz |
| Refresh frequency | >3000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Self-check technology | LED spot self-check, communications check, power check, |
| temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature
protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
Why choose us?
1Quick delivery:
In case not delay your useage,we'll try our best to send the goods
for you,generally we deliver the goods according to the area and
countries,but always be 12-15 working days after we receive your
final payment.
2.Satisfied price:
we have been in this field for more than 10 years,and we also
understand the needs of customers,we promise high quality products
for good price,because of the professional technology can help us
control the cost,so the competitive price is based on the
quality,equipment and technicians.Only all the parts work together
can we give you the good price!
3.Good after-sales service:
We provide free technical support,online inquiry.And any questions
we will reply within 4 hours.
The goods sent you we promise the whole new and not the second
hand,any problems about machine we can help you to solve during the
warranty!
Welcome to visit our website and inquire more info!!!
