P6 rgb SMD full color indoor LED Display screen unit
board,32*32pixels,192mm*192mm
Applications:
Commercial advertising outdoor led display for mobile media,
outdoor led display for stadium hoardings, outdoor led display
module for mobile trailers, outdoor led display for shopping malls
for signage, outdoor led display for banks and stock exchanges for
exchange rates, outdoor led display for trains and buses for
information and instructions, outdoor led display for airports,
Telecom outdoor led display system.
What We Do:
We offer you the possibility of broadcasting advertisements on our
screens, a unique advertising medium that combines the advantages
of outdoor and television advertising. This kind of advertising is
very important if you want to create and support your company image
or encourage the sale of your products. A wide range of sizes is
available: outdoor, indoor displays, semi-outdoor displays. There
are also full color, two color and single color for you to choose
from. Customer-designed sizes are acceptable.
Specifications :
| outdoor SMD P6 |
| Resolution/mm | 6 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 43222m² |
| Module resolution | 27778 |
| Module size/mm | 192x192mm |
| View distance | 14-300m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >7500cd/㎡ |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | 1/13 SCANNING |
| Frame rate | 60Hz |
| Refresh frequency | >3000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Self-check technology | LED spot self-check, communications check, power check, |
| temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature
protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
Adjustable Angle
With a high refresh rate, high brightness, high intensity, clearly
showing every exciting events moment.
Cabinet angle is adjustable between 65°,70°,75°,80°,85°,90° to
ensure optimal viewing effect.
Strong impact resistance
Soft mask and top protection board design, it can effectively
protect the screen and personnel safety when the screen body being
strong shocks.
Easy disassembly
Easy snap fittings connection between cabinet designed is for quick
installation and removal Screen to create a very convenient
conditions.
Fibre transmission
Adopt efficient optical fiber transmission system, effectively
reduce the signal delays, to ensure the consistency of the
tournament picture playback.
Safe and reliable
High-strength anti-aging fabric, IP65 protection class, able to
withstand any environment test.
Adopt professional aviation plug connectors, stable and safety.
Our service1.
Your inquiry about our products or prices will be replied within 24
hours2. OEM and ODM, any of your customized lamps and lanterns we
can help you to design and put into production3. agency rights for
your unique design and some of our existing models4. protection of
your sales area, design concepts, and all your private
information5. top quality + reasonable price + responsible
after-sales service=success and victory
Trade Terms1.
Packing Shock-proof wooden packing, air box or carton packing
2. Payment: T/T: T/T, 40% deposit before production, 60% final
payment before delivery 3. Freight charges are quoted according to
your requirements 4. Shipping port: Shenzhen, Mainland China 5.
Warranty time: 2-3 years 6.
6. Delivery time: 3-12 working days
We are a China LED display manufacturer, our main products are
stadium LED display, square LED display, giant LED TV wall, airport
LED display, advertising LED billboard, mobile LED rental display,
stage LED display board, wall large LED display, exhibition,
shopping malls and so on, so our outdoor and indoor LED display is
favored by customers in many countries. Therefore, our outdoor and
indoor LED displays are favored by customers in many countries,
As a result, our outdoor and indoor LED displays are favored by
customers in many countries, such as: For more detailed information
about LED displays, please contact us, we can meet the needs of the
international market for high-quality indoor LED displays, outdoor
LED displays, rental LED displays and creative LED displays!
Welcome to visit our website and inquire us more info,waiting for
you all the time!!!
