Brand Name : | Shichuangxinke |
Model Number : | SCXK-P5 |
Certification : | CE RoHS FCC CCC TUV UL |
Price : | USD600-1800 per square meters |
Payment Terms : | L/C, T/T, Western Union |
Supply Ability : | 5000sqm per month |
Delivery Time : | 7-10 working days after deposit payment received |
high quality china hd p5 led display screen hot photos rental led
panel p5 outdoor led displays
Advantages:
1. We have been focusing on indoor and outdoor LED display and LED
modules for 5 years.
2. We are manufacturers and wholesalers of LED display, LED
modules, flexible LED strips, injection LED modules and LED
accessories. We are able to control quality and save costs.
3. 100% quality control inspection before shipment.
4. We have passed CE, FCC, ROHS, CCC and ISO9001 certifications to
ensure high quality.
5. We have special LED chips and materials. (High brightness, zero
turn-off LED)
Trade Terms:
Delivery Time: Within 3 working days after receiving payment.
Payment Terms: 100% payment by Paypal/Western Union or T/T before
shipment.
Packing: Strong cardboard box.
Warranty: 2 years warranty.
Shipping Method: Ship outdoor LED modules by DHL, UPS, Fedex and
EMS.
Shipping Cost: We will calculate the best shipping cost for you
after you tell us the quantity and shipping address.
Specifications :
outdoor SMD P5 | |||||
Resolution/mm | 5 | ||||
Pixel configuration | 1R1G1B | ||||
Pixel density/pixels/m² | 4000/m² | ||||
Module resolution | 64x32 | ||||
Module size/mm | 320x160mm | ||||
View distance | 14-300m | ||||
Single point brightness adjust | Can be added | ||||
Single point color adjust | Can be added | ||||
White balance brightness | >7500cd/㎡ | ||||
Color temperature | 6500K-9500K | ||||
Horizontal view angle | 120(degrees) | ||||
Vertical view angle | 60(degrees) | ||||
Signal Process bit | 10 or 16bit | ||||
Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
Driving mode | Constant driving current | ||||
Scanning mode | 1/16 SCANNING | ||||
Frame rate | 60Hz | ||||
Refresh frequency | >3000Hz | ||||
Control mode | Computer synchronous | ||||
Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
255 steps. No grey loss | |||||
Out of control point | <1/10000 | ||||
Working hours | ≥72hours | ||||
Mean Time Between Failure | >5000hours | ||||
Life time | 100000hours | ||||
Life-all-white(brightness halving) | 50000hours | ||||
Environment temperature range | Operating temperature range: -20-45℃ | ||||
Self-check technology | LED spot self-check, communications check, power check, | ||||
temperature monitor(need customization) | |||||
Remote monitoring | Remote supervision and control, record potential fault, | ||||
send out warning signs to the operators.(need customization) | |||||
Software environment | WindowsNT,Windows1999,WindowsXP | ||||
Luminous point width between centres | Deviation<3% | ||||
Brightness uniformity | <10% | ||||
Color uniformity(chromaticity coordinate) | ±0.003 | ||||
Power supply request | AC85-264V(50Hz-60Hz) | ||||
Contrast | (1000:1) | ||||
System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
Humidity(working) | working:10-95% | ||||
Humidity(storing) | storing:10-95% |
Applications:
On roof of building LED Billboard
Mounted on building LED Billboard
Put on steel pole LED Billboard
Cross bridge information LED Billboard
Shopping Mall LED Billboard
Commercial Advertising LED Billboard
Church LED Billboard
Road Show LED Billboards
High Speed Way LED Advertising Billboard
♦ Frequently Asked Questions
What kind of payment terms you can accept ?
We can accept T/T and Western Union.
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection
before shipment ensure the quality of
our products continuity.
What is your delivery time ?
Within 7-35 days according to your area and quantity.
Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and
professional production ensure
our led display’s competitiveness.
![]() |
