SCXK super brightness p6 outdoor full color advertising led display
for road sign
Shenzhen Shichuangxinke leads the way in LED display manufacturing
& technology. Its outdoor & indoor commercial advertising LED
display, rental use LED display, fixed installation LED display,
sports stadium perimeter LED display, mobile trailer LED display,
water floating LED display, transparent LED curtain display,
digital LED billboard, LED components & complete LED full color
video systems undergo stringent quality control at ISO
9001-certified manufacturing plants.
We offer users friendly products that optimize productivity and
business efficiency and maintain the highest standards of design
and quality. Customer satisfaction is our prime objective and our
high quality LED video display screen used in more than 140
countries and win a high reputation.
Designed with utmost precision and advanced technologies, the new
series of our Outdoor Full Color Stadium Perimeter Screen finds its
extensive usage in sporting events, exhibitions and allied.Sourced
from some of the distinguished manufacturers of the industry, the
range available with us comes in following
Spec
| Model | Unit | P6 |
| Pixel pitch | mm | 6 |
| Pixel resolution | pixel/m² | 27778 |
| Pixel configuration | - | DIP346 1R1G1B Oval LED lamp |
| Viewing angles | horizontal | 110° at 50% brightness |
| Weight | kg/m² | 52 |
| Brightness | CD/m² | 6000 |
| Contrast ratio | - | 3,000:1 |
| Color temperature | K | 6,500 |
| Color processing | bit/color | 12 |
| Colors | number | 1.07 billion |
| Grayscale | steps | 1024level |
| Best viewing distance | m | 6 -100 |
| Refresh rate | Hz | ≥1,000 |
| Control system | - | LINSN |
| Life time | h | 75,000 to 50% brightness down |
| Power consumption | W/m² | 800 |
| (maximum/average) | W/cabinet | 280 |
| Working voltage | - | AC220V or AC110V / 50-60 Hz |
| Cabinet dimension | mm | customised |
| Cabinet material | - | cold rolled steel |
| Protection rate | IP | front: IP65, back: IP55 |
| Working temperature | °C | -20 to +55 |
| Working humidity | RH | 10 to 90% |
| Image source with LED video processor | - | HDMI, CVBS, YC, YUV, RGB DVI, SDI/HDSDI |
| Image source without video processor | - | DVI |
| Maximum transmitting distance | m m | <100 with network cable <2,000 with optical fiber cable |
| Cabinet interfaces | - | 2 signal ports, 2 power ports |
| Maximum per power entry | cabinets | 220V power input: 6 110V power input: 3 |
| Maintenance | - | back |
The epistar Led chip. with SMD and DIP Technology .
we adopt the epistar led chip from Taiwan,DIP and SMD led display
module will be available
The wire or wireless controll system are available .( 3g and wifi
controll will be welcome)
Factory Equipment
Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Re flow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection
(AOI) Equipment.
Competitive Advantage:
1. 2 years’ warranty with free repair service
2. 24/7 Hours online Remote Support
3. Solution and PCB design
4. Free factory training
5. On site installation instruction and regular inspection
6, Small order accepted.
Package
Payment and delivery
1) T/T, 30% deposit, 70% before shippment.
2) 100% Western Union in advance.
♦ Why choose us:
Continues Quality
With more than 10 years experience in led display
producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products
continuous quality.
Competitive Price
With large scale production capacity and professional production
technology,our company have built
effective modular production.We always stick to promote the
technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill
it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the
products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and
we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly
perfect our products.
♦ Frequently Asked Questions
What kind of payment terms you can accept ?
We can accept T/T and Western Union.
What about your Led Display quality ?
Checking in the whole manufacturing process&100% inspection
before shipment ensure the quality of
our products continuity.
What is your delivery time ?
Within 7-35 days according to your area and quantity.
Is your LED display competitive ?
Yes,we are led display manufacturer for more than 10 years.Mass and
professional production ensure
our led display’s competitiveness.
Thank you very much for viewing our website, and wish you a nice
day!
