    High Stability P6.67 HD Module LED Display, Easy To Install And Maintain

    Ask Lasest Price
    Brand Name : Shichuangxinke
    Model Number : SCXK-P6.67
    Certification : CE RoHS FCC CCC TUV UL
    Price : negotiation
    Payment Terms : L/C, T/T, Western Union, D/A, D/P, MoneyGram
    Supply Ability : 5000sqm per month
    Delivery Time : 7-10 working days after deposit payment received
    • Product Details
    • Company Profile

    High Stability P6.67 HD Module LED Display, Easy To Install And Maintain

    P6.67 Front Access Module LED Display for Easy Install & Maintenance


    Customer Service:


    1) Warranty Period: One year after shipment from the factory
    2) Warranty coverage: LED modules, power supplies, control systems and other accessories (this warranty does not cover accessories purchased from other manufacturers)
    3) Repair Method:
    Repair, express delivery, etc.
    4) Repair response time:
    Repair method: Upon receipt of the returned product, the repair will be completed and returned to the user within 24 hours;
    Telephone or Internet: Contact the user within 2 hours after receiving the information, and solve the problem within 8 hours;
    On-site mode: (domestic users only) after receiving the repair report, users in Guangdong Province within 48 hours to give a reply, users outside Guangdong Province within 72 hours to give a reply. Under special circumstances, the two sides will solve the problem by friendly negotiation.

    Specifications :
    outdoor SMD P6.67
    Resolution/mm6.67
    Pixel configuration1R1G1B
    Pixel density/pixels/m²22478/m²
    Module resolution48x24
    Module size/mm320x160mm
    View distance14-300m
    Single point brightness adjustCan be added
    Single point color adjustCan be added
    White balance brightness>7500cd/㎡
    Color temperature6500K-9500K
    Horizontal view angle120(degrees)
    Vertical view angle60(degrees)
    Signal Process bit10 or 16bit
    Grey process1024x1024x1024 16834x16834x16834 65536x65536x65536
    Control distancesInternet cable:100m, multimembrane:500m, monofilm:2km
    Driving modeConstant driving current
    Scanning mode1/4SCANNING
    Frame rate60Hz
    Refresh frequency>3000Hz
    Control modeComputer synchronous
    Brightness adjusted rangeManual, automatic operation, stepless continuous adjusted
    255 steps. No grey loss
    Out of control point<1/10000
    Working hours≥72hours
    Mean Time Between Failure>5000hours
    Life time100000hours
    Life-all-white(brightness halving)50000hours
    Environment temperature rangeOperating temperature range: -20-45℃
    Self-check technologyLED spot self-check, communications check, power check,
    temperature monitor(need customization)
    Remote monitoringRemote supervision and control, record potential fault,
    send out warning signs to the operators.(need customization)
    Software environmentWindowsNT,Windows1999,WindowsXP
    Luminous point width between centresDeviation<3%
    Brightness uniformity<10%
    Color uniformity(chromaticity coordinate)±0.003
    Power supply requestAC85-264V(50Hz-60Hz)
    Contrast(1000:1)
    System protection

    Moistureproof,dustproof,high temperature protection,

    anti-corrosion,anti-burning,anti-static,anti-vibration

    Humidity(working)working:10-95%
    Humidity(storing)storing:10-95%

    Advantages:


    1. High temperature resistant and aging resistant PC materials are applied in the modules to get rid of the mosaic problem even after long time use.
    2. High brightness enables longer viewing distance and ensures the spectators far from the screen can still enjoy what is shown, even under direct sunlight.
    3. The cabinets, featuring great moisture and corrosion proofing, enable themselves to work in all weather conditions.
