5mm pitch indoor full color smd large stage led display,with 1/16 scanning

Shenzhen Shichuangxinke electronic co., ltd is a standard manufacturer of led display ,owned about 100 employees. company was established in 2005, over these years,our led displays enjoy good reputation from our customers.

We have 12-year design experience of offering solution, installation, and after-sales service, etc. According to different environment conditions, too cold temperature till -40℃ or too hot temperature till +55℃, we carefully choose different suitable materials and make the best offer for every customer. It differs in cables, LED lamps, plastic masks, waterproof materials, IC, etc. Faced with a variery of requirements, we offer flexible diverse solutions. We offer 24-hour all- direction online service.

The feature of our led display as follows.

1. Good quality raw material, accurate technique and careful inspection insures

3, High color uniformity and clear image can bring you a vivid audio visual effect.

4, Using virtual pixels, better viewing effect for both text & graphic and video.

Specifictions
LED Lamps	Type			SMD3528(High Brightness LEDs)
	LED Standard			Real Pixel(1R1G1B)
	Red Wavelength			625-630nm
	Green Wavelength			515-530nm
	Blue Wavelength			465-475nm
LED Module	Pixel Pitch			5mm
	Module Size			160mx160m
	Module Resolution			32*32dots
LED Cabinet	Cabinet Size			800mmX800mm
	Cabinet Resolution			160pixels *160pixels
	Cabinets Material			Iron steel cabinet
LED Display	Pixel Density			62500pixels/sq.m
	Drive IC			MBI5024
	Power Supply			Series connection
	Brightness			>2500cd/sqm
	Display Color			16.7million
	Viewing Angle			110°(Horizontal),50°(Vertical)
	Best Viewing Distance			5m~200m
	Max Power Consumption			600 w/sq.m
	Average Power Consumption			300 w/sq.m
	Weight			35Kgs/sq.m
	Refresh Rate			3000hz
	Input Voltage			AC220V/50H or AC110V/60H
	Output Voltage			DC5V,40A
	Grey Scale Levels			16bit
	Display Colors			R(1024) x G(1024) x B(1024)
	MTBF			10,000 hours
	Life-span			100,000 hours
	Protection Level			IP43
	Failure percentage of leds			less than 0.0003
	Working Temperature			-25℃~65℃
	Drive Mode			1/16 scaning
	Working Humidity			10%~99%
Control System	Control method			Synchronization & Asynchronization
	Control System			LINSN Control System (sender,receiver,HUB with 75 interface,software)
	Software			LED Studio (LINSN)
	Input Signal			MPG/MPEG/MPV/MPA/AVI/VCD/SWF/RM/RA/RM/ASF/BMP/GIF/PCX/TXT/DOC.etc
	PC Operating system			Microsoft Windows 7, 98, 2000, XP and Vista

The epistar Led chip. with SMD and DIP Technology .

we adopt the epistar led chip from Taiwan,DIP and SMD led display module will be available

led screen feature

1.Wide application field & short ROI time:

commercial advertising LED display screen, Stadium perimeter LED display screen, Mobile trailer LED display screen for mobile media,floor tile screen ect.

shopping mall LED display screen for logo showing, bank&stock exchange LED display screen for rates showing, train & bus station LED display screen

air port LED display screen, telecommunication LED display screen system for information showing and instruction .

2. High Contrast ratio: 4000:1
Which is a very high level to ensure a vivid image of our LED display screen system.

3. First-class LED chip:
Supplied by Nichia of Japan & other high strictly selected LED chip to ensure the long lifetime and high brightness of our LED display screen system

4. Clear vivid image quality:
Even in direct full-on sunlight to ensure you attract more audience to get short ROI of your LED display screen's

investment.

Methods for Quality Assurance

a. Aging testing :100% fully test Condition: 72 hours with 256 gray level

b. Vibration Testing:Condition: 3-5 min up and down in 5mm range

Advantage

1. OEM service,No MOQ

2. Easy installation,regular items in Stocks

3. Offering free design drawing as requested.

4. Remote controlling and adjusting are available.

5. Wooden case or flight case,you are the boss.

6. Your reply will be replied within 24 hours.

7. Fast delivery: Usually 6-8 working days

8. Excellent R&D team,factory Price and assure you quality goods.

Payment and delivery

1) T/T, 30% deposit, 70% before shippment.
2) 100% Western Union in advance.

♦ Why choose us:

Continues Quality

With more than 10 years experience in led display producing,equipments are updated regularly.What’s

more,unique standardized and module production ensure our products continuous quality.

Competitive Price

With large scale production capacity and professional production technology,our company have built

effective modular production.We always stick to promote the technical innovation and reduce cost to

benefit customers.

Fast Delivery

Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

inventory will be used to maintain your uninterrupted supply of the products.

Perfect Service

Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

you.

After-sales:We will track the products usage and then constantly perfect our products.

♦ FAQ

What kind of payment terms you can accept ?

We can accept T/T and Western Union.

What about your Led Display quality ?

Checking in the whole manufacturing process&100% inspection before shipment ensure the quality of

our products continuity.

What is your delivery time ?

Within 7-35 days according to your area and quantity.

Is your LED display competitive ?

Yes,we are led display manufacturer for more than 10 years.Mass and professional production ensure

our led display’s competitiveness.
