    P8 Steel Cabinet Outdoor LED Die-Cast Aluminum Screen For Advertising

    Ask Lasest Price
    Brand Name : SCXK
    Model Number : SCXK-P8
    Certification : CE,ROHS ,FCC,UL
    Price : negotiation
    Payment Terms : L/C, T/T, Western Union
    Delivery Time : 5-8days
    • Product Details
    • Company Profile

    P8 Steel Cabinet Outdoor LED Die-Cast Aluminum Screen For Advertising

    Welcome to visit shichuangxinke electronic Co.,ltd


    Shenzhen Shichuangxinke Electronics Co.,Ltd is established in 2005. we are a leading manufacturer and provider of technical solution of full color indoor an outdoor ledisplay,rental LED display, led modules and so on,


    We have our outstanding research and develop department and after-sales service workers, the separately design ability.Our product mainly included the RGB led display,outdoor full color led display,indoor full color led display,curtain led display, advertising led display,stage led display,led billboard,bi color led display,single color led display,rental led display,stadium led display,led display module,car led sign display,hanging led display,mobile truck led display..


    It can be used on the shopping mall,bank, bus station, train station, center of downtown, airport, school, factory, bus, taxi, and so on. we adopt many methods and very good after-sales service to sell our product all over the world.. Whenever and wherever we are , we always take the principle that professional makes good quality, provide the perfect product and service for our customer.


    The outdoor smd P8 led display ( outdoor P8 smd led display parameter)


    Outdoor P8 full color led display
    LED LampsTypeSMD3535(High Brightness LEDs)
    LED StandardReal Pixel(1R1G1B)
    Red Wavelength625-630nm
    Green Wavelength515-530nm
    Blue Wavelength465-475nm
    LED ModulePixel Pitch8mm
    Module Size256mmx128mm
    Module Resolution32*16dots
    LED CabinetCabinet Size1024mmX768mm
    Cabinet Resolution128pixels *96pixels
    Cabinets MaterialSealed Iron Cabinet
    LED DisplayPixel Density15625pixels/sq.m
    Drive ICMBI5024
    Power SupplySeries connection
    Brightness>8500cd/sqm
    Display Color16.7million
    Viewing Angle110°(Horizontal),50°(Vertical)
    Best Viewing Distance8m~200m
    Max Power Consumption600 w/sq.m
    Average Power Consumption300 w/sq.m
    Weight45Kgs/sq.m
    Refresh Rate3000hz
    Input VoltageAC220V/50H or AC110V/60H
    Output VoltageDC5V,40A
    Grey Scale Levels16bit
    Display ColorsR(1024) x G(1024) x B(1024)
    MTBF10,000 hours
    Life-span100,000 hours
    Protection LevelIP65
    Failure percentage of ledsless than 0.0003
    Working Temperature-25℃~65℃
    Drive Mode1/4 scaning
    Working Humidity10%~99%
    Control SystemControl methodSynchronization & Asynchronization
    Control SystemLINSN Control System (sender,receiver,HUB with 75 interface,software)
    SoftwareLED Studio (linsn)
    Input SignalMPG/MPEG/MPV/MPA/AVI/VCD/SWF/RM/RA/RM/ASF/BMP/GIF/PCX/TXT/DOC.etc
    PC Operating systemMicrosoft Windows 7, 98, 2000, XP and Vista

    P8 Steel Cabinet Outdoor LED Die-Cast Aluminum Screen For Advertising


    Here is our parameter!that include the outdoor and indoor full color led display


    the outdoor full color led display module ( smd and dip are available)
    NumberDrive modeModuel sizeResolutionLed standardpixel density
    P41/8 scan256x128mm64x323in162500
    p4.811/13scan250x250mm52x523in143222
    p51/8 scan160x160mm32x323in140000
    P61/8 scan192x192mm32x323in127778
    P81/4scan256x128mm32x163in115625
    P101/4scan160x160mm16x163in110000
    P121/4scan192x192mm16x163in16944
    P16static scan256x256mm16x163in13906
    P20static scan320x160mm16x83in12500
    P25static scan200x200mm8x83in11600
    P31.25static scan250x250mm8x83in11024
    the indoor full color led display module( indoor usage only)
    Numberdrive modemodule sizeresolutionled standardpixel density
    p1.9231/32scan246x246mm128x1283 in 1270420
    p21/32scan128x64mm64x323 in 1250000
    p2.51/16scan160x160mm64x643 in 1160000
    p31/16scan192x192mm64x643 in 1111111
    p3.911/16scan250x250mm64x643 in 165410
    p41/16scan256x128mm64x323 in 162500
    p51/16/scan320x160mm64x323 in 140000
    p61/16scan384x192mm64x323 in 127778
    p7.621/8 scan244x244mm32x163 in 117222
    p101/8 scan320x160mm32x163in 110000

    The special feature of outdoor led display cabinet .


    Our certification as follows: ( we regard our quality as our life.and regard our reputation as our enterprise life.

    all the led display will be through the strict test before the deliverty time .And guarantee ,3 years warranty,more than 10 years lifeuse .


    ♦ Applications


    Stage,Sports,advertising,traffic,events,stadium,shopping center,airport,exhibitions, car shows,

    fashion shows, concerts, ceremonies, entertainment,etc.


    ♦ Our advantages

    Professional Manufacturer of led display


    1. OEM service,No MOQ

    2. Easy installation,regular items in Stocks

    3. Offering free design drawing as requested.

    4. Remote controlling and adjusting are available.

    5. Wooden case or flight case,you are the boss.

    6. Your reply will be replied within 24 hours.

    7. Fast delivery: Usually 6-8 working days

    8. Excellent R&D team,factory Price and assure you quality goods.


    ♦ Production process:


    1) Incoming Inspection→2) SMD→3) Plug-in

    →4) Wave Soldering→5) After Welding→6) Testing

    →7) Semi Finished Aging→8) Module Assembly

    →9) Gluing→10) Finished Aging→11) Detection Finishing Warehousing


    ♦ Packaging and shipping


    Wooden case or flight case package are available.

    Shipping by sea,air or DHL,multiple shipping ways for your choice.


    ♦ Why choose us:

    Continues Quality

    With more than 10 years experience in led display producing,equipments are updated regularly.What’s

    more,unique standardized and module production ensure our products continuous quality.


    Competitive Price

    With large scale production capacity and professional production technology,our company have built

    effective modular production.We always stick to promote the technical innovation and reduce cost to

    benefit customers.


    Fast Delivery

    Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency

    inventory will be used to maintain your uninterrupted supply of the products.


    Perfect Service

    Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to

    you.

    After-sales:We will track the products usage and then constantly perfect our products.
