SMD 3535 Water Proof IP65 10mm Led Display Epistar Chip 3 Years
Warranty
Our factory has its own characteristic culture, which is full of
passion and warmth, and has its own sunshine motto. Every employee
working here is not only a worker, but also a friend, and our
friendship is rich, and all of our employees are doing their best
work every day. Our work motto is: passionate work, happy life; our
spirit is: strict requirements, conscious dedication; our goal is:
customer first, service first; our service concept is: loyal
service, wonderful life.
1. The cabinets, featuring great moisture and corrosion proofing,
enable themselves to work in all weather conditions.
2. Superb refresh rate provides you coherent video effects to meet
your needs for high display quality.
3. Superb cost effective offers you both top notch quality and
reasonable price, maximizing the value of your investment
Application:
Outdoor full color LED display could be used in outdoor environment
such as airport, highway, cultural or relax square, commercial
walking street, residential sub-district, downtown, with various
real-time signal sources and the speciality of waterproof,
dustproof, antistatic, its purpose is to propagandize outdoor
advertising or play the important news or events or TV program etc.
Our led display feature as follows:
1). Wide application field : Outdoor Commercial advertising LED display screen, LED display
board for shopping mall,Stadium perimeter LED display
,bank&stock exchange LED display screen for rates showing,train
& bus station LED display screen .
2). High brightness:7000cd/m2 Automatic or manual adjustment of the brightness of the display.
3).Top LED chip: Supplied by Silan of china & other high strictly selected LED chip
to ensure the long lifetime and high brightness of our LED display
system.
4). Clear vivid image quality: Throughout the show, the picture clear, bright color.
5).Installation is simple,easy to use: Easy and simple installation interface and user friendly software
to ensure that customers use easily.
The parameter as follows:
| The outdoor full color outdoor P10 stadium led display |
| LED Lamps | Type | SMD3535(High Brightness LEDs) |
| LED Standard | Real Pixel(1R1G1B) |
| Red Wavelength | 625-630nm |
| Green Wavelength | 515-530nm |
| Blue Wavelength | 465-475nm |
| LED Module | Pixel Pitch | 10mm |
| Module Size | 320mmx160mm |
| Module Resolution | 32*16dots |
| LED Cabinet | Cabinet Size | 960mmX960mm |
| Cabinet Resolution | 96pixels *96pixels |
| Cabinets Material | Sealed Iron Cabinet |
| led screen | Pixel Density | 10000dots/sqm |
| Drive IC | MBI5024 |
| Power Supply | Series connection |
| Brightness | >8500cd/sqm |
| Display Color | 16.7million |
| Viewing Angle | 160°(Horizontal),110°(Vertical) |
| Best Viewing Distance | 10m~200m |
| Max Power Consumption | 600 w/sq.m |
| Average Power Consumption | | | 300 w/sq.m |
| Weight | 45/sq.m |
| Refresh Rate | 3000hz |
| Input Voltage | AC220V/50H or AC110V/60H |
| Output Voltage | DC5V,40A |
| Grey Scale Levels | 16bit |
| Display Colors | R(1024) x G(1024) x B(1024) |
| MTBF | 10,000 hours |
Features:
1.High and adjustable LED brightness can meet the demands of the
changing requirement of customer in different environments.
2. No mosaic display due to excellent flatness and nice uniformity
of light-emitting
3.Wide viewing angle and the horizontal angle can reach 120°m. The
images display effect will not Change largely in the range.
4. Virtual pixel display screen can be adopted for outdoor displays
to increase the resolution up to four times of real pixel, making
the images softer and vivider
5. LED Single-lamp maintenance with low cost.
6. Good heat dissipation capability because of the unique design of
vent fan.
7. Environmental-friendly and energy-saving.
